Multiple room colors scheme

Revit
1

Hi everyone,

any chanche to get multiple colors room scheme in one view? any idea?

2

How would you do this manually in Revit?

3

hi Jacobsmall,
thanks for replying!
In Revit i tried to apply a color scheme to rooms and then with filter overriding them, but im not getting what im looking for. I need actually to add a pattern scheme to an existing room color scheme…

4

Try to make them white (solid fill) in the color schema, next override with a pattern.

5

Thanks Marcel for the idea,
i need to preserve the original room color schema and add “tranparent” pattern on top…
Unfortunatly i can not get the result with Revit filters…

6

I thought only Materials can have 2 patterns applied atm.

So, a hacky workaround would be to use the Room boundary for a transparent Filled Region with the appropriate pattern.

Alternatively, it might be worth exploring a filter with a hatch in a Finish Floor (if you guys model those), combined with the Color Scheme of the Room in the view.

Both are not optimal, but I think those are the ways I would do it manually now in Revit. So worth exploring in Dynamo.

1 Like
7

Hi all,

looks like the Rooms colorschema Parameters are not exposed in the API. I guess there is no way to archive this :confused:

8

Have a look at the items on the 'For Everyon" about halfway down the page. :slightly_smiling_face:
