Hello all,
We are working a project within a historic building. The entrance has a rotunda space we would like to unwrap or flatten into linework/drafting view or export at CAD.
Does anyone have a method for this?
Thanks in advance
Hello all,
We are working a project within a historic building. The entrance has a rotunda space we would like to unwrap or flatten into linework/drafting view or export at CAD.
Does anyone have a method for this?
Thanks in advance
Hi @craig_SW,
If the facade is not too complicated, you could try with the Unfold Concave or Unfold Convex nodes.
HI Alban,
Thanks! I’ll take a look.
Craig
Hi Alban,
The model is a Scan-to-BIM survey so the wall isn’t perfectly round. It’s a family made up of different components… so it’s not picking up the geometry.
you could try https://dynamobim.org/dynamounfold/ - but it will not unfold curved surfaces, you will need to rationalize it into planar surfaces yourself or triangulate it.
Hi,
Thanks, useful for the future, but the geometry is scan-to-BIM data of an existing building and we cannot rationalise.
