Does someone know how to set the Assembly Code file with Dynamo in Revit.
Only found the node how to get the file path…
http://dynamobim.org/forums/topic/get-assembly-code-settings-in-python/
I don’t even know what a Assembly Code Table is, but the
AssemblyCodeTable Class in the Revit API has only got one Method, and that’s the GetAssemblyCodeTable Method
http://www.revitapidocs.com/2016/26b23f25-ef12-5368-3f4b-6097f93ce312.htm
That makes me think it’s not possible to set it. Someone else might be able to give a more certain answer than me.
Assembly code is a UNIFORMAT classification (Alphanumeric string) for categorizing the built environment. Anything constructed can be classified by these codes.
@Jeremy_Tammik - Any suggestions on how to SET assembly code in PYHTON? (Thanks in advance : )
I am having a similar issue- ran across “UNIFORMAT_CODE” as a built in parameter - see section under:
if param.lower()=="assembly code":
outSub.append("UNIFORMAT_CODE:")
element.SetParameterByName(BuiltInParameter.UNIFORMAT_CODE,dat[hI]) #p=header/param name, dat[i] corresponding data at index
outSub.append("BuiltInParamSuccess!")
This is not working either (Correctly formatted code below).
# Default imports
import clr
clr.AddReference("RevitAPI")
clr.AddReference("RevitNodes")
elements = IN[0] ##Elements in the mode
headers = IN[1] ##Headers for reference
data = IN[2] ##Data LIST of values for PARAMS.
###Initialize
out=[]
outMain=[]
outSub=[]
found=0
##Find "MARK" Position from headers
for markPos, mark in enumerate(headers):
if mark=='Mark': ##Found mark in headers proceed
found=1
break ##BREAK loop with current header index
if found==1: ##NEED better system of parameters to key-in on other than mark with a "+"
for element in elements: ##Step through all the elements provided
emark=element.GetParameterValueByName('Mark') ##Get the mark of the current element
for dat in data: ##For each of the list(Data points) provided
if dat[markPos]==emark: ##If the data in the [markpos]
##(Which is the mark we are looking for) matches the
##Current elements mark - we have a match to push data
outMain=[] ##Reset the list collector for reporting
for hI, param in enumerate(headers): ##hI count based on header Information to corresponding data
##-For parameters that are headers in the file
outSub=[] ##Reset the list collector for reporting
try:
outSub.append(param) ##Report parameter to push
outSub.append(dat[hI]) ##Report data psuhed to param
element.SetParameterByName(param,dat[hI]) #p=header/param name, dat[i] corresponding data at index<<-##Does nothing for "Assembly Code"
outSub.append("SetParam Success!") ##If it reaches here it was successful!
except: ##Error occured above
outSub.append("Checking BuiltInParameters:")
try: ##Attempt to unwrap to set type param
#outSub.append("Unwrap:")
#element=UnwrapElement(eleent)[0]
if param.lower()=="assembly code":
outSub.append("UNIFORMAT_CODE:")
element.SetParameterByName(BuiltInParameter.UNIFORMAT_CODE,dat[hI]) #p=header/param name, dat[i] corresponding data at index
outSub.append("BuiltInParamSuccess!")
except:
outSub.append("ERROR in unwrap_set") #Add "error" to the return if it flakes
##outMain.append(element) ##Append element to outMain
outMain.append(outSub) ##Append Parameters success/fail
out.append(outMain)
out.insert(0,[["****Tab must be 'Sheet1'***************\n****'Mark' in row 1 must be defined****"]])
OUT=outI tried setting by name for “Assembly Code” in the 1st attempt to se in the code and it failed.
Got the idea for built-in parameters from:
https://forums.autodesk.com/t5/revit-api-forum/assembly-code-in-system-families/td-p/4790573
AND
really need to know how to set family TYPE parameters in Python- as well I suspect the “Assembly Code/Uniformat” is a special parameter.
Here is how to set a builtinparameter (typeparameter) with python. This is untested code.
import clr
# Import Revit API
clr.AddReference('RevitAPI')
from Autodesk.Revit.DB import *
# Import ToDSType(bool) extension method
clr.AddReference('RevitNodes')
import Revit
clr.ImportExtensions(Revit.GeometryConversion)
clr.ImportExtensions(Revit.Elements)
# Import DocumentManager and TransactionManager
clr.AddReference('RevitServices')
import RevitServices
from RevitServices.Persistence import DocumentManager
from RevitServices.Transactions import TransactionManager
doc = DocumentManager.Instance.CurrentDBDocument
# Input
element = UnwrapElement(IN[0])
valueToSet = IN[1]
#Get the type
elementType = doc.GetElement(element.GetTypeId())
# Get the parameter
parameter = elementType.get_Parameter(BuiltInParameter.UNIFORMAT_CODE)
#Set the parameter in a Transaction
TransactionManager.Instance.EnsureInTransaction(doc)
parameter.Set(valueToSet)
TransactionManager.Instance.TransactionTaskDone()
OUT = 0
1 Like
Much Obliged!
Will test and debug it and then push it back to the forum.
Thanks!
Ron Allen | B+P BIM Manager - Rocky Mountain Area | Revit BIM ARCH.IV.NCARB.IDP | D 1-303-740-2716 | Ron.Allen@AECOM.commailto:Ron.Allen@AECOM.com | AECOM | www.AECOM.comhttp://www.aecom.com/ Denver
PPlease consider the environment before printing this e-mail.
Admittedly I don’t know how unwrap works… so I had to adapt the former part of the code and add the unwrap later- still errors out setting the parameter (Can you unwrap an element?)
in the 2nd TRY there is the ### Unifromat scan:
ele=UnwrapElement(element) #Get the type ##UNIFORMAT SET elementType = doc.GetElement(ele.GetTypeId()) # Get the parameter parameter = elementType.get_Parameter(BuiltInParameter.UNIFORMAT_CODE) ## #Set the parameter in a Transaction TransactionManager.Instance.EnsureInTransaction(doc) parameter.Set(data[hI]) TransactionManager.Instance.TransactionTaskDone()
Entire code:
# Default imports
import clr
clr.AddReference("RevitAPI")
clr.AddReference("RevitNodes")
import Revit #################################
clr.ImportExtensions(Revit.GeometryConversion) #################################
clr.ImportExtensions(Revit.Elements) #################################
# Import DocumentManager and TransactionManager##################################
clr.AddReference('RevitServices') #################################
import RevitServices #################################
from RevitServices.Persistence import DocumentManager #########################
from RevitServices.Transactions import TransactionManager #####################
doc = DocumentManager.Instance.CurrentDBDocument #############################
elements = IN[0] ##Elements in the mode
headers = IN[1] ##Headers for reference
data = IN[2] ##Data
###Initialize
out=[]
outMain=[]
outSub=[]
found=0
##Find "MARK" Position from headers
for markPos, mark in enumerate(headers):
if mark=='Mark': ##Found mark in headers proceed
found=1
break ##BREAK loop with current header index
if found==1: ##Consider adding additional parameters to key-in on other than mark
for element in elements:
emark=element.GetParameterValueByName('Mark')
for dat in data:
if dat[markPos]==emark:
outMain=[]
for hI, param in enumerate(headers): ##hI count based on header to corresponding data For parameters that are headers in the file
outSub=[]
try:
outSub.append(param)
outSub.append(dat[hI])
element.SetParameterByName(param,dat[hI]) #p=header/param name, dat[i] corresponding data at index
outSub.append("SetParam Success! \t")
except:
outSub.append("ERROR in element.SetParameterByName \t") #Add "error" to the return if it flakes
try: ###################################################################### Unifromat scan
ele=UnwrapElement(element) ##############################################
#Get the type ########################################################## UNIFORMAT SET
elementType = doc.GetElement(ele.GetTypeId()) ######################
# Get the parameter ######################
parameter = elementType.get_Parameter(BuiltInParameter.UNIFORMAT_CODE) ##
#Set the parameter in a Transaction
TransactionManager.Instance.EnsureInTransaction(doc)
parameter.Set(data[hI])
TransactionManager.Instance.TransactionTaskDone()
except:
outSub.append("ERROR in set element.GetTypeId() (Uniformat) \t")
##outMain.append(element) ##Append element to outMain
outMain.append(outSub) ##Append Parameters success/fail
out.append(outMain)
out.insert(0,[["****Tab must be 'Sheet1'***************\n****'Mark' in row 1 must be defined****"]])
OUT=out
Your unwrapping looks fine. While troubleshooting, it would be better to remove the try-except blocks to see what error messages you get.
Warning: IronPythonEvaluator.EvaluateIronPythonScript operation failed.
Traceback (most recent call last):
File “”, line 55, in
NameError: name ‘BuiltInParameter’ is not defined
Are you missing a reference?
# Import Revit API
clr.AddReference('RevitAPI')
from Autodesk.Revit.DB import *Yep- Missed the import
Now it is a different error:
Warning: IronPythonEvaluator.EvaluateIronPythonScript operation failed.
Traceback (most recent call last):
File “”, line 58, in
TypeError: expected int, got list
# Default imports
import clr
clr.AddReference("RevitAPI")
clr.AddReference("RevitNodes")
import Revit #################################
clr.ImportExtensions(Revit.GeometryConversion) #################################
clr.ImportExtensions(Revit.Elements) #################################
# Import DocumentManager and TransactionManager##################################
clr.AddReference('RevitServices') #################################
import RevitServices #################################
from RevitServices.Persistence import DocumentManager #########################
from RevitServices.Transactions import TransactionManager #####################
doc = DocumentManager.Instance.CurrentDBDocument #############################
elements = IN[0] ##Elements in the mode
headers = IN[1] ##Headers for reference
data = IN[2] ##Data
###Initialize
out=[]
outMain=[]
outSub=[]
found=0
##Find "MARK" Position from headers
for markPos, mark in enumerate(headers):
if mark=='Mark': ##Found mark in headers proceed
found=1
break ##BREAK loop with current header index
if found==1: ##Consider adding additional parameters to key-in on other than mark
for element in elements:
emark=element.GetParameterValueByName('Mark')
for dat in data:
if dat[markPos]==emark:
outMain=[]
for hI, param in enumerate(headers): ##hI count based on header to corresponding data For parameters that are headers in the file
outSub=[]
try:
outSub.append(param)
outSub.append(dat[hI])
element.SetParameterByName(param,dat[hI]) #p=header/param name, dat[i] corresponding data at index
outSub.append("SetParam Success! \t")
except:
outSub.append("ERROR in element.SetParameterByName \t") #Add "error" to the return if it flakes
try: ###################################################################### Unifromat scan
ele=UnwrapElement(element) ##############################################
#Get the type ########################################################## UNIFORMAT SET
elementType = doc.GetElement(ele.GetTypeId()) ######################
# Get the parameter ######################
parameter = elementType.get_Parameter(BuiltInParameter.UNIFORMAT_CODE) ##
#Set the parameter in a Transaction
TransactionManager.Instance.EnsureInTransaction(doc)
parameter.Set(data[hI])
TransactionManager.Instance.TransactionTaskDone()
except:
outSub.append("ERROR in set element.GetTypeId() (Uniformat) \t")
##outMain.append(element) ##Append element to outMain
outMain.append(outSub) ##Append Parameters success/fail
out.append(outMain)
out.insert(0,[["****Tab must be 'Sheet1'***************\n****'Mark' in row 1 must be defined****"]])
OUT=outCleared the othe rmessage with:
parameter.Set(str(data[hI][0]))
for the data…
Almost have it- posting the wrong data to the assembly code but it is setting it …
Finally! Thanks for your help!
# Default imports
import clr
clr.AddReference("RevitAPI")
clr.AddReference("RevitNodes")
from Autodesk.Revit.DB import * #################################
import Revit #################################
clr.ImportExtensions(Revit.GeometryConversion) #################################
clr.ImportExtensions(Revit.Elements) #################################
# Import DocumentManager and TransactionManager##################################
clr.AddReference('RevitServices') #################################
import RevitServices #################################
from RevitServices.Persistence import DocumentManager #########################
from RevitServices.Transactions import TransactionManager #####################
doc = DocumentManager.Instance.CurrentDBDocument #############################
elements = IN[0] ##Elements in the mode
headers = IN[1] ##Headers for reference
data = IN[2] ##Data
###Initialize
out=[]
outMain=[]
outSub=[]
found=0
##Find "MARK" Position from headers
for markPos, mark in enumerate(headers):
if mark=='Mark': ##Found mark in headers proceed
found=1
break ##BREAK loop with current header index
if found==1: ##Consider adding additional parameters to key-in on other than mark
for element in elements:
emark=element.GetParameterValueByName('Mark')
for dat in data:
if dat[markPos]==emark:
outMain=[]
for hI, param in enumerate(headers): ##hI count based on header to corresponding data For parameters that are headers in the file
outSub=[]
try:
outSub.append(param) ###ADD PARAMS TO Output list
outSub.append(dat[hI]) ###ADD TABS + Data to output list
element.SetParameterByName(param,dat[hI]) ###Attempt set data header/param name, dat[i] corresponding data at index
outSub.append("SetParam Success!") ###If it succeedes report it
except: ### If if failed...################################################
if param == "Assembly Code": ##SPECIAL ODD-BALL CASE for SYSTEM TYPE PARAM (Assembly Code)####
try: ##################################Assembly Code = Unifromat scan
ele=UnwrapElement(element) ##########
#Get the type ###################### (UNIFORMAT TYPE param)
elementType = doc.GetElement(ele.GetTypeId()) ######################
# Get the parameter###################
parameter = elementType.get_Parameter(BuiltInParameter.UNIFORMAT_CODE)
#Set the parameter in a Transaction###
TransactionManager.Instance.EnsureInTransaction(doc)
parameter.Set(str(dat[hI])) ##FROM THE current DAT line of DATA return the data from the hI Index position in the list
#Set the parameter end Transaction###
TransactionManager.Instance.TransactionTaskDone()
outSub.append("Set ASSEMBLY CODE Param Success!")
except:
outSub.append("ERROR set element.GetTypeId() (Uniformat)")
outMain.append(outSub) ##Append Parameters success/fail
out.append(outMain)
out.insert(0,[["****Tab must be 'Sheet1'***************\n****'Mark' in row 1 must be defined****"]])
OUT=out
2 Likes
Hello Ron. I really apprieciate your work, but can you make your script more understandable? What do you mean by the folowing parameters?
elements = IN[0] ##Elements in the mode
headers = IN[1] ##Headers for reference
data = IN[2] ##Data
Maybe you can add some printcreens from your Dynamo workaround to this post?
thanx!
elements = IN[0] ##Elements in the model - Elements to run the script with (1d List)
headers = IN[1] ##Headers for reference - The headers stripped out from the excel file (Also the Revit PARAMETER Names)(1d list)
data = IN[2] ##Data - The remaining excel rows of data.(List of list - 2d list)
thurevit3 , Did you solve the problem of the question? I would also like to set the Assembly Code with Dynamo in Revit
Create a Python Script with the following Code:
With a filepath as input, (referring to the location of the .txt file) this should do the work
import clr
clr.AddReference('RevitAPI')
from Autodesk.Revit.DB import*
clr.AddReference('RevitServices')
from RevitServices.Persistence import DocumentManager
from RevitServices.Transactions import TransactionManager
doc = DocumentManager.Instance.CurrentDBDocument
uiapp = DocumentManager.Instance.CurrentUIApplication
app = uiapp.Application
filepath = UnwrapElement(IN[0])
p = ModelPathUtils.ConvertUserVisiblePathToModelPath(filepath)
s = ExternalResourceReference.CreateLocalResource(doc, ExternalResourceTypes.BuiltInExternalResourceTypes.AssemblyCodeTable, p, PathType.Absolute);
TransactionManager.Instance.EnsureInTransaction(doc)
AssemblyCodeTable.GetAssemblyCodeTable(doc).LoadFrom(s, KeyBasedTreeEntriesLoadResults());
TransactionManager.Instance.ForceCloseTransaction()
OUT = s.GetReferenceInformation()
6 Likes
