Modeling a bridge

Revit
1

Hello

I want to model a box girder bridge, I have the design drawings, and i have created the cross-section (profile) of the bridge in Revit.

What I want now is to model it along the corridor.

I have looked high and low, watched alot of YouTube videos, some of which use a package called dynabridge (didn’t work), some used OOTB nodes, also didn’t work …

Looked here, and learned about a package called civilconnection I believe, but I couldn’t find any guide or tutorials on it!

Could someone please help me with this, or if anyone knows about a guide I can read.

2

Did you take a look here?

1 Like
3

Do you have a corridor reference model or excel data?

image1326×736 14.5 KB

In the image green line is slope reference and dot is profile reference point.
My model is nested in generic model adaptive model to use “Create form”.
I used “Familyinstance.byface” to place profile family to each point.

This also will help for your work.
https://www.autodesk.com/autodesk-university/class/MEP-Modeling-Made-Easy-Dynamo-2017

1 Like
4

Maybe use this technique to get rid of the overlaps.

1 Like
5

Have a look to my Au presentation. it present how to model Bridge and linear str.

4 Likes
